64 Rockwell Automation Publication 750-IN100B-EN-P - July 2017
Chapter 4 Mechanical and Electrical Installation
Figure 23 - Frame 12 Drives
M1M0L1L0 L3 LCL2L2 L4 M2 M3 M4
Module Type Remove Position No. Shipping Split Section
Line side converter L0, L1 Section 1 of 3 (left section)
L2, L3 Section 2 of 3 (center section)
LCL filter LCL2
Motor side inverter M0, M1, M2, M3, M4 Section 3 of 3 (right section)
To Next Page
