140 Maintaining Your Control System

3. Install a replacement fuse. See the figure below for fuse

placement.

POWER

Fuse

3-Pin Jumper

ATTENTION

The exposed pins on the 3-pin jumper is electrically live.

Contact with the pin may cause injury to personnel.
