Allen-Bradley SLC 500

Publication 1747-UM011G-EN-P - June 2008
Replacement Parts 171
Replacement Terminal Blocks
Other Replacement Hardware
Description Cat. No.
Replacement Terminal Block (Blue) - Used with dc I/O modules, catalog numbers 1746-IB16, 1746-IC16, 1746-IH16,
1746-IV16, 1746-OBP8, 1746-OB16, 1746-OB16E, 1746-OBP16, 1746-OVP16 1746-OV16, 1746-IN16, 1746-IG16,
1746-1746OG16
1746-RT25B
Replacement Terminal Block (Orange) - Used with relay output modules, catalog numbers 1746-OW16, 1746-OX8 1746-RT25C
Replacement Terminal Block (Green) - Used with Specialty I/O modules, catalog numbers 1746-HSCE, 1746-IO12,
1746-NR4, 1746-NI8
1746-RT25G
Replacement Terminal Block (Red) - Used with ac I/O modules, catalog numbers 1746-IA16, 1746-OA16, 1746-IM16,
1746-OAP12
1746-RT25R
Replacement Terminal Block - 2-position terminal block used with analog outputs, catalog numbers 1746-NO4I,
1746-NO4V
1746-RT26
Replacement Terminal Block - 8-position terminal block used with analog outputs, catalog numbers 1746-NO4I,
1746-NO4V
1746-RT27
Replacement Terminal Block - Used with analog input modules, catalog numbers 1746-NI4, 1746-NIO4I, 1746-NIO4V,
1746-FIO4I, 1746-FIO4V
1746-RT28
Replacement Terminal Block - Used with RIO Communication modules, catalog numbers 1747-SN, 1746-DSN,
1746-DCM
1746-RT29
Replacement Terminal Block - 6-position DH-485 plug/connector;
used with DH-485 Link Coupler, catalog number 1747-AIC and Advanced Interface Converter, catalog number
1761-NET-AIC
1746-RT30
Replacement Terminal Block - used with SLC 500 Remote I/O Adapter module, catalog number 1747-ASB 1746-RT31
Replacement Terminal Block - used with Thermocouple/mV module, catalog number 1746-NT4 1746-RT32
Replacement Terminal Block - 3-position DH+ connector; used with SLC 5/04 processors, catalog numbers 1747-L541,
1747-L542, -L542P, 1747-L543
1746-RT33
Replacement Terminal Block (Green) - used with Thermocouple/mV Input module, catalog number 1746-NT8 1746-RT34
Replacement Terminal Block (Green) - used with RTD/resistance Input module, catalog number 1746-NR8 1746-RT35
Description Cat. No.
Replacement Fuses — Five fuses per package. Orders must be for multiples of five. -
Catalog number for 1746-P1 power supply. 1746-F1
Catalog number for 1746-P2 power supply. 1746-F2
Catalog number for 1746-P3 power supply. 1746-F3
Fixed I/O ac units, MDL 1.25 Ampere. 1746-F4
Fixed I/O dc units, MDL 1.6 Ampere. 1746-F5
Catalog numbers for 1746-OBP16 and 1746-OVP16 output modules. 1746-F8
Catalog numbers for 1746-OAP12 output module. 1746-F9
