81 Publication 1747-UM011G-EN-P - June 2008
Chapter
5
Identifying the Components of Your Processor
This chapter covers the following:
• SLC 5/01 hardware features
• SLC 5/02 hardware features
• SLC 5/03 hardware features
• SLC 5/04 hardware features
• SLC 5/05 hardware features
• Keyswitch for the SLC 5/03, SLC 5/04, and SLC 5/05 processors
SLC 5/01 Processor
Hardware Features
The SLC 5/01 processor provides:
• two choices of program memory size - 1 K or 4 K instructions.
• control of up to 3840 input and output points.
• powerful ladder logic programming instruction set.
• subroutines.
• a DH-485 communication channel (peer-to-peer communication
response to message commands only).
• capacitor backup for the 1747-L511 module; battery backup for
the 1747-L514 module.
• program using your programming software.
• UL listed to US and Canadian Safety Standards, CE compliant,
C-Tick marked.
The figure on page 82 shows the hardware components of the SLC 5/01
processor (1747-L511 and 1747-L514).
