220 RS-232 Communication Interface

Applications for the RS-232

Communication Interface

The figures below illustrate different applications for the RS-232

communication interface.

DF1 Full-duplex Peer-to-peer

Half-duplex with Slave-to-slave Routing

IMPORTANT

The 1747-KE module does not support slave-to-slave transfers.

Modem

SLC 5/03 Modular Controller SLC 5/03 Modular Controller

Modem

ModemModem Modem

WINtelligent Linx or RSLinx

Running DF1 Half-duplex

Protocol (Master)

SLC 5/03 Modular Controller SLC 5/03 Modular Controller
