170 Replacement Parts
Cable Connectivity Summary
RJ45 to 6-Pin Phoenix Connector Communication Cable - This 3 m (9.8 ft) cable is used to connect the SLC 500 fixed,
SLC 5/01, SLC 5/02, and SLC 5/03 processor RJ45 port to port 3 of the 1761-NET-AIC advanced interface converter.
1761-CBL-AS03
RJ45 to 6-Pin Phoenix Connector Communication Cable - This 9.5 m (31.2 ft) cable is used to connect the SLC 500 fixed,
SLC 5/01, SLC 5/02, and SLC 5/03 processor RJ45 port to port 3 of the 1761-NET-AIC advanced interface converter.
1761-CBL-AS09
Catalog 1492 pre-wired interface cables 1492
Description Cat. No.
For Connectivity Between These Devices Preferred Cable
Cat. No.
These Cables
May Be Used
1746-A4, 1746-A7, 1746-A10, or
1746-A13 chassis
1746-A4, 1746-A7, 1746-A10, or
1746-A13 chassis
1746-C7
1746-C9
1746-C16
-
1747-PIC Personal Interface Converter
1747-DTAM-E Data Table Access module
2707-Lxxx, 2707-Vxxx DTAM Plus
1747-AIC Isolated Link Coupler
SLC 500 processors (DH-485 channel)
1747-C10 1747-C11
1747-C20
1747-AIC Isolated Link Coupler SLC 500 processors (DH-485 channel) 1747-C11 1747-C10
1747-C13
1747-C20
1747-KE DH-485/RS-232C interface
module
1746-BAS BASIC module
1747-AIC Isolated Link Coupler 1747-C13 1747-C11
1747-C10
1746-xx32 32 point I/O modules 1492-IFM40x 1492-CABLExH-
SLC 5/03 processor (RS-232 channel 0)
SLC 5/04 processor (RS-232 channel 0)
SLC 5/05 processor (RS-232 channel 0)
Personal computer serial port (9-Pin
DTE)
1747-UIC RS-232 port
1747-CP3 -
1746-I/O 1492-IFMxx interface modules 1492-CABLExx -
1747-SN Remote I/O Scanner
1747-DCM Direct Communication Module
1747-ASB SLC Remote I/O Adapter
module
SLC 5/04 processors (1747-L541,
1747-542, and 1747-543)
Remote I/O network Belden 9463 -
1747-AIC Isolated Link Coupler
1770-KF3 DH-485 communication
interface
1747-AIC Isolated Link Coupler Belden 9842 or 3106A -
1747-UIC RJ-485 port SLC 500 processors (DH-485 channel) 1747-C13 -
