Allen-Bradley SLC 500 - 13-Slot Modular Chassis

Publication 1747-UM011G-EN-P - June 2008
Mounting Your SLC 500 Control System 77
13-slot Modular Chassis
(1) Dimensions for 1746-P1 power supply.
(2) Dimensions for 1746-P2, 1746-P3, 1746-P5, 1746-P6, and 1746-P7 power supplies.
(3) Dimensions for 1746-P4 power supply.
145
(5.71)
171
(6.73)
140
(5.51)
1.0
(0.04)
158
(6.22)
140
(5.51)
140
(5.51)
560
(22.05)
540
(21.26)
55
(2.17)
11 Dia.
(0.433)
5.5 Dia.
(0.217)
171
(6.73)
105
(4.13)
(5.51)
140
14
(0.55)
586
(23.07)
5.5 Dia
(0.217)
Front View
millimeters
(inches)
Left Side View
(1)(2)(3)
