Publication 1747-UM011G-EN-P - June 2008
Quick Start for Experienced Users 23
9. Establish communication to the processor. Reference
Refer to the following to establish communication between the processor and your
personal computer.
Chapter 8
(Starting Up Your
Control System)
Set the communication parameters of software to match the default parameters of the processor.
Processor Procedure
SLC 5/01 Connect 1747-PIC interface from the processor to your personal computer serial port or
connect 1747-UIC interface from the processor to your personal computer USB port, or use a
1784-PKTX(D) or 1784-PMCK interface.
SLC 5/02 Connect 1747-PIC interface from the processor to your personal computer serial port or
connect 1747-UIC interface from the processor to your personal computer USB port, or use a
1784-PKTX(D) or 1784-PMCK interface.
SLC 5/03 Connect the 1747-PIC interface from the processor to your personal computer serial port or
connect the 1747-UIC interface from the processor to your personal computer USB port to
the processor by using the 1747-C13 or 1747-CP3 cable. You can also use a 1784-PKTX(D) or
1784-PCMK interface, or a 1747-CP3 cable from channel 0 of the processor to the personal
computer serial port.
SLC 5/04 Connect a 1747-CP3 cable from channel 0 of the processor to the personal computer serial
port or connect the 1747-UIC interface from channel 0 of the processor to your personal
computer USB port, or use a 1784-PKTX(D) or 1784-PCMK interface.
SLC 5/05 Connect a 1747-CP3 cable from channel 0 of the processor to the personal computer serial
port, or connect the 1747-UIC interface converter from channel 0 of the processor to your
personal computer USB port. For Ethernet connection, connect channel 1 of the processor
and the PC Ethernet card to an Ethernet hub by using 10/100Base-T compatible cable.
(1)
(1)
EtherNet/IP address must first be set via BOOTP or an RS-232 connection. See appendix C for more information.
Comms Channel Channel 0
Configuration
Channel 1 Configuration
SLC 5/01 and 5/02 SLC 5/03, 5/04, and 5/05 SLC 5/03 SLC 5/04 SLC 5/05
DH-485:
19.2 Kbaud
node address = 1
DF1 Full-duplex:
no handshaking
19.2 Kbaud
CRC Error Check
duplicate packet,
detect on
no parity
DH-485:
19.2 Kbaud
node address = 1
DH+:
57.6 Kbaud
node address = 1
Ethernet:
BOOTP enabled
