Allen-Bradley SLC 500

Publication 1747-UM011G-EN-P - June 2008
Calculating Heat Dissipation for the SLC 500 Control System 265
Specialty Modules 1746-BAS NA 3.750 3.800
1746-BLM NA 5.00 5.00
1746-BTM NA 2.59 2.59
1746-HSCE NA 1.600 1.600
1746-HSCE2 NA 1.25 1.25
1746-HSRV NA 1.50 1.50
1746-HSTP1 NA 1.50 1.50
1746-INT4 NA 1.26 1.26
1746-NR4 NA 1.500 1.500
1746-NR8 NA 1.82 1.82
1746-NT4 NA 0.800 0.800
1746-NT8 NA 2.28 2.28
1746-QS NA 9.80 9.80
1746-QV NA 1.075 1.075
Communication Modules 1747-ACN15 NA 4.5 4.5
1747-ACNR15 NA 4.5 4.5
1747-ASB NA 1.875 1.875
1747-BSN NA 4.0 4.0
1747-DCM NA 1.800 1.800
1747-KE NA 3.750 3.800
1747-KFC15 NA 3.200 3.200
1747-SCNR NA 4.5 4.5
1747-SDN NA 2.5 2.5
1747-SN NA 4.500 4.500
Peripheral Devices 1747-AIC NA 2.000 2.000
1747-DTAM NA 2.500 2.500
1747-PIC NA 2.000 2.000
1747-PSD NA NA NA
1761-NET-AIC
(2)
NA 2.500 2.500
1761-NET-DNI
NA 2.500 2.500
1761-NET-ENI(W)
(2)
NA 2.000 2.000
(1)
Power supply loading for Series D and later modules.
(2)
Current for the 1761-NET-AIC and 1761-NET-ENI may be supplied from the SLC power supply or from an external 24V dc source.
Hardware
Component
Cat. No. Watts per Point Minimum Watts Total Watts
