Amada Vipros 357 Queen - Plan View - Vipros 357 Queen with V357 Hs Conveyor and MP1225 Loader

Vipros 357 Queen with Fanuc 18PC User Pre-installation Guide ©Amada America, Inc.
Print Date 01/24/2001 Revision 4.0 This document available on the World Wide Web at http://www.amada.com Page 16 of 37
Plan View - Vipros 357 Queen
with V357hs conveyor and MP1225 loader
V357hs Conveyor
66"
39"
E3
Fanuc 18P Control
H
y
draulic Uni
t
72.0" to Load Position
74.41" to Edge of Table
148.82" Machine Width
Access Required
this area for
scrap removal
55"
26
"
28"
59"
14"
30"
37"
57"
SBC 5.5 Chiller
P1
E2
E1
59.37" Maximum
1
0"
Machine
Centerline
VIPROS 357 QUEEN
Optional Material
Supports Required
Optional Material
Supports Required
50" Working Range
100" Maximum Travel Area 50" Material
183.8" Machine Length
288.0" Maximum Material Travel Area 144" Material
389" Recommended Safety / Maintenance Area 40" from all components
441" Recommended Safety / Maintenance Area 40" from all components
Electrical Requirements
Vipros 357 Queen
Vipros 357 Queen
Compressed Air Requirements
230 / 460 / 3 / 60 ±10% 30 kVA
SBC EX5.5 Chiller
230 or 460 / 3 / 60 ±10% 15 kVA
80 psi @ 8.8 ft³/min.
76 amps @ 230 / 3 / 60 VAC
38 amps @ 460 / 3 / 60 VAC
37 amps @ 230 / 3 / 60 VAC
19 amps @ 460 / 3 / 60 VAC
V357hs Conveyor
208 - 230 / 460 / 3 / 60 ±10% .8 kVA
2.1 amps @ 208 / 3 / 60 VAC
2.0 amps @ 230 / 3 / 60 VAC
1.0 amps @ 460 / 3 / 60 VAC
MP1225 Loader
MP1225 Loader 75 psi @ 31.8 ft³/min.
29 amps @ 200 / 3 / 60 VAC
200 / 3 / 60 ±10%, 10 Kva
To operate at 230 / 460 VAC a step up
transformer with the following service is
required
26 amps @ 230 / 3 / 60 VAC
13 amps @ 460 / 3 / 60 VAC
E1
E2
E3
E4
P1
P2
Scale
12"12"12"
MP1225
Xformer
MP1225 Loader
Forklift Access
Required This Area
For Material / Parts
Loading / Unloading
65.95"
188.06" MP1225 Length
75.41" to Edge of MP1225
217.15"
141.74" MP1225 Loader Width
P2
E4
