Specifications - Motion Package
Travel Method X and Y axes work piece movement
Control Method X, Y, T & C
Drive Motors Fanuc AC Servo (X, Y, T, C)
Maximum Sheet Size 50" (Y) x 144" (X) with one repositioning cycle. Additional support
tables are required for material lengths greater than 72”
Maximum Sheet Thickness Ball Transfer Table
Brush Table
0.250"
0.135"
Maximum Material Weight Ball Transfer Table
Brush Table
220 lb.
110 lb.
Maximum Axis Travel 72.0" (X) by 50" (Y)
Max. Table Speed ( X / Y / Combined ) 2559 ipm / 1968 ipm / 3228 ipm
Punching Accuracy ±0.004"
Positioning Accuracy ±0.001"
Repeatability ±0.001"
