Amada Vipros 357 Queen - End View - Vipros 357 Queen

Vipros 357 Queen with Fanuc 18PC User Pre-installation Guide ©Amada America, Inc.
Print Date 01/24/2001 Revision 4.0 This document available on the World Wide Web at http://www.amada.com Page 17 of 37
End View - Vipros 357 Queen
7.9"
3.9"
22.8"
98.7"
29.5"
110.6"
Shipping Width w/o Crate
35.4"
19.7"
12"12" 12"
Scale
148.8"
