Machine Leveling
Proper Machine leveling is critical to the Vipros 357 Queen performing as designed.
Materials and tools required:
Supplied with the machine:
Assorted thickness machine leveling shim stock
Anchor bolts
Supplied by AESI service:
Spirit level capable of reading 0.0005"/ft
One (1) 12 ton hydraulic bottle jack
Not supplied:
Additional shim stock of 0.005" thickness may be required to achieve a properly leveled machine.
Rocking Test
After the machine frame has been leveled the use of the following G-code is necessary to determine that the machine frame
is properly leveled and balanced.
Should the machine frame vibrate or move excessively during the rocking test the machine frame must be re-leveled using
the procedure in this manual.
Should the proper leveling technique not eliminate the excessive frame motion, consideration must be given to relocation of
the machine or replacement of the existing floor with an adequate foundation.
Set M500 values to Top Position 0.080", Bottom Position, 0.080", Slow Position 0.000"
Repeat test with X-axis movement values of 0.500", 1.000", and 4.000"
G92X72.000Y50.000
G06A.100B0
M500
N1
G91G70X-.25Tttt(Use any valid tool number)
G70X.25
M97P1
G50
