Vipros 357 Queen with Fanuc 18PC User Pre-installation Guide ©Amada America, Inc.
Print Date 01/24/2001 Revision 4.0 This document available on the World Wide Web at http://www.amada.com Page 30 of 37
Step 5 Fill each of the Anchor Rod holes to within 2 inches of the floor surface with
the Adhesive compound. Do not overfill.
Existing Floor
Step 6 Attach the hex nut and flat washer on the Anchor Rod and place the Anchor
Rod into the drilled hole.
Using a twisting motion to move the Anchor Rod through the epoxy
compound, seat the flat washer and hex nut against the top of the machine
foot.
Existing Floor
Step 7
Step 8.
Allow the Adhesive to harden for 24 hours.
Tighten the 4 hex nuts.
E
xisting F
loor
