VCU118 Board User Guide 99
UG1224 (v1.5) March 15, 2023
Chapter3: Board Component Descriptions
FMCP Connector J22
[Figure 2-1, callout 33]
The HPC connector at J22 implements a subset of the full FMCP connectivity:
• 116 single-ended or 58 differential user-defined pairs (34 LA pairs: LA[00:33],
24 HA pairs: HA[00:23])
• 24 transceiver differential pairs
• 6 transceiver differential clocks
• 2 differential clocks
• 239 ground and 16 power connections
The FMPC J22 connections to FPGA U1 are documented in Table 3-32. The net names shown
in the table are as connected to FMCP HSPC J22 pins.
Table3‐32 : J22 VITA 57.4 FMPC HSPC Connections
J22
FMCP
HSPC
Pin
Schematic Net Name
I/O
Standard
FPGA
(U1) Pin
J22
FMCP
HSPC
Pin
Schematic Net Name I/O Standard
FPGA
(U1) Pin
J22 Sections A/B Connections to FPGA U1
A2 FMCP_HSPC_DP1_M2C_P LVDS AN45
B1 NC NA NA
A3 FMCP_HSPC_DP1_M2C_N LVDS AN46 B4 FMCP_HSPC_DP9_M2C_P LVDS AF43
A6 FMCP_HSPC_DP2_M2C_P LVDS AL45 B5 FMCP_HSPC_DP9_M2C_N LVDS AF44
A7 FMCP_HSPC_DP2_M2C_N LVDS AL46 B8 FMCP_HSPC_DP8_M2C_P LVDS AG45
A10 FMCP_HSPC_DP3_M2C_P LVDS AJ45 B9 FMCP_HSPC_DP8_M2C_N LVDS AG46
A11 FMCP_HSPC_DP3_M2C_N LVDS AJ46 B12 FMCP_HSPC_DP7_M2C_P LVDS N45
A14 FMCP_HSPC_DP4_M2C_P LVDS W45 B13 FMCP_HSPC_DP7_M2C_N LVDS N46
A15 FMCP_HSPC_DP4_M2C_N LVDS W46 B16 FMCP_HSPC_DP6_M2C_P LVDS R45
A18 FMCP_HSPC_DP5_M2C_P LVDS U45 B17 FMCP_HSPC_DP6_M2C_N LVDS R46
A19 FMCP_HSPC_DP5_M2C_N LVDS U46 B20 FMCP_HSPC_GBTCLK1_M2C_P(5) LVDS U39.2
A22 FMCP_HSPC_DP1_C2M_P LVDS AP42 B21 FMCP_HSPC_GBTCLK1_M2C_N(5) LVDS U39.1
A23 FMCP_HSPC_DP1_C2M_N LVDS AP43 B24 FMCP_HSPC_DP9_C2M_P LVDS AJ40
A26 FMCP_HSPC_DP2_C2M_P LVDS AM42 B25 FMCP_HSPC_DP9_C2M_N LVDS AJ41
A27 FMCP_HSPC_DP2_C2M_N LVDS AM43 B28 FMCP_HSPC_DP8_C2M_P LVDS AK42
A30 FMCP_HSPC_DP3_C2M_P LVDS AL40 B29 FMCP_HSPC_DP8_C2M_N LVDS AK43
A31 FMCP_HSPC_DP3_C2M_N LVDS AL41 B32 FMCP_HSPC_DP7_C2M_P LVDS K42
A34 FMCP_HSPC_DP4_C2M_P LVDS T42 B33 FMCP_HSPC_DP7_C2M_N LVDS K43
A35 FMCP_HSPC_DP4_C2M_N LVDS T43 B36 FMCP_HSPC_DP6_C2M_P LVDS M42
A38 FMCP_HSPC_DP5_C2M_P LVDS P42 B37 FMCP_HSPC_DP6_C2M_N LVDS M43
A39 FMCP_HSPC_DP5_C2M_N LVDS P43 B40 NC NA NA
