Table 4-25 SPI Interface Signal Description
Signal Name Type Description
SPI_A_MOSI DIO SPI master output, slave input A
SPI_A_MISO DIO SPI master input, slave output A
SPI_A_SCLK DIO SPI clock A
SPI_A_SS0 DIO SPI slave select 0 A
SPI_B_MOSI DIO SPI master output, slave input B
SPI_B_MISO DIO SPI master input, slave output B
SPI_B_SCLK DIO SPI clock B
SPI_B_SS0 DIO SPI slave select 0 B
Table 4-26 Remote Interface Signal Description
Signal Name Type Description
IR_REMOTE_IN DI IR remote control input
IR_REMOTE_OUT DO IR remote control output
Table 4-27 Time Division Multiplexing Signal Description
Signal Name Type Description
MCLK_0 DO Master clock output 0, for I2S master mode
MCLK_1 DO Master clock output 1, for I2S master mode
TDMA_DIN0 DI Data input 0 of TDM port A
TDMA_DIN1 DI Data input 1 of TDM port A
TDMA_D0 DIO Data input/output 0 of TDM port A
TDMA_D1 DIO Data input/output 1 of TDM port A
TDMA_SCLK DO Bit clock output of TDM port A
TDMA_FS DO Frame sync output of TDM port A (Word clock of I2S)
TDMA_SLV_SCLK DI Bit clock input of TDM port A
TDMA_SLV_FS DI Frame sync input of TDM port A (Word clock of I2S)
TDMB_DIN0 DI Data input 0 of TDM port B
TDMB_DIN1 DI Data input 1 of TDM port B
TDMB_DIN2 DI Data input 2 of TDM port B
TDMB_DIN3 DI Data input 3 of TDM port B
TDMB_D0 DIO Data input/output 0 of TDM port B
TDMB_D1 DIO Data input/output 1 of TDM port B
TDMB_D2 DIO Data input/output 2 of TDM port B
TDMB_D3 DIO Data input/output 3 of TDM port B
TDMB_D4 DIO Data input/output 4 of TDM port B
