2.8.1.2 Loading the machine using acrane
For loading with acrane, the machine is provided with a1-point
or 4-point suspension.
Use acrane with asucient load capacity.
Observe relevant national safety measures while load-
ing the machine using acrane.
Before lifting, the articulation joint of the machine must
be secured with the strut 1 against tilting and secured
with the pin 2 and the lock 3.
Observe safety regulations while loading and unloading!
Use acrane with asucient load capacity!
Use corresponding and unbroken hoisting slings with
asucient load capacity!
The machine must be tied to the 4-point or 1-point
suspension!
The maximum permissible working load for the one-
point suspension is 2.7 tons.
Only atrained person (slinger) may carry out the tying of
the machine!
Do not enter under the lifted load!
