Ammann ARX 23-2C - Engine Oil Check

121ARX 23-2 T4i, ARX 26-2 T4i
593018
615065
x
y
593019
MAINTENANCE MANUAL
3.6.2 Engine oil check
Wait for about 5 min. until the oil ows down into the engine
sump.
Take out the oil dipstick, wipe it, insert fully back and take it out
again to read out the oil level.
Keep the level within the range of gauge marks imprinted in the
dipstick. The lower mark shows the lowest possible oil level, the
upper mark indicates the highest.
Rell the oil as required.
Rell engine oil through the ller neck.
Check the engine for leaks and remove the cause.
Check the engine for damaged and/or missing parts and for
changes in appearance.
Note
The total volume of oil in the engine is 7 litres (1.85 US gal).
Do not use the engine unless the oil level in the engine
is correct.
Carry out the check after the oil has been cooled down.
Fill up the same oil type; see Chap. 3.2.1.
Stop the oil soaking into the ground.
