87ARX 23-2 T4i, ARX 26-2 T4i

S591002

S591003

S591007

589D011

OPERATING MANUAL

Release the canopy by pulling out the lever (1) slightly and lo-

wer the canopy.

Remove the cotter pins on the left and right side of the ROPS

frame.

Loosen the rear pegs (2) on the left and right side of the ROPS

frame by approximately two turns.
