8 Maintenance
BNNbOO
ID: 1138310 Issue date January 01, 2010
125
Consumables, tightening torques
Consumables
Description Brand Quantity Prod. No.
Engine oil Motorex Topaz 15W50 1 l
921197
Grease Motorex Moly 218 400 g
1111368
Grease Motorex 174 4.5kg
1147048
Grease Blaser Foodgrease SPM00 14 kg
1075038
Anti-freeze Motorex green 30 l
922341
Bolt locking Loctite 243 (blue) 50 ml
907977
Bolt locking Loctite 243 (blue) 250 ml
907975
Bolt locking Loctite 262 (red) 50 ml
907978
Bolt locking Loctite 262 (red) 250 ml
907979
Paint spray RAL 1016 Sulfur yellow 400 ml
922700
Paint spray RAL 6033 Mint turquoise 400 ml
922701
CAUTION!
All screws must be secured using Loctite 243/blue (Loctite 262/red for
screws or nuts on rubber bearings) unless specified otherwise.
Tightening torques
SW Bolt diameter Steel quality Tightening torque in Nm
10 M6 8.8 10
13 M8 8.8 25
17 M10 8.8 49
19 M12 8.8 86
24 M16 8.8 210
24 M16 10.9 290
30 M20 8.8 410
