6 Operating
BNNbOO
ID: 1138310 Issue date January 01, 2010
56
Starting the engine
Joint protection
Ensure that the joint protection (1) is
secured as shown and the safety
spring is engaged.
WARNING
Accident hazard
When the joint protection is secured
the steering is blocked.
Protection against vandalism
Ensure that the vandalism protection
(1) is clapped fully to the rear as
shown in the image.
Driver’s position
1 Drive lever
2 Speed adjusting lever
3 Emergency-stop button
4 Ignition switch
If the driver's seat is occupied, the
seat switch releases the controls.
The seat switch must not be shorted.
If the emergency stop button (3) is activated, release it by rotating it clockwise
once. In the "America" version release the emergency stop button by pulling
upwards.
1
3
4
1
2
1
