Ammann AV40-2 - AV23 - AV40 Hydraulics Diagram Legend

11 Hydraulics diagram
BNNbOO
ID: 1138310 Issue date January 01, 2010
149
AV23 - AV40 hydraulics diagram legend
Element Description
1
Drive pump
2
Vibration steering pump
3
Feed pump
4
Vibro switch valve
5
Front drive motor
6
Rear drive motor
7
Vibration front
8
Vibration rear
9
Steering unit
10
Hydraulic tank
11
Return filter
12
Oil cooler
13
Steering
15
Electrically switchable flow divider option
