7 Options
BNNbOO
ID: 1138310 Issue date January 01, 2010
84
Interval sprinkler
Switching continuous sprinkling
on and off
Turn the sprinkler switch from position
0 to position 1 to activate continuous
sprinkling.
Interval sprinkler
Turn the switch further right to switch
on interval sprinkling.
Interval sprinkler pause times
Turn the switch gradually to the right
to change the duration of sprinkling
pauses step by step.
Pos. 0 Off
Pos. 1 Continuous sprinkling
Pos. 2 2 seconds
Pos. 3 4 seconds
Pos. 4 8 seconds
Pos. 5 14 seconds
Pos. 6 20 seconds
Pos. 7 Not assigned
NOTE
(Nothing happens in position 7. This is the same condition as when the
switch is in position 0 [off]).
ATTENTION!
Machine damage!
If your machine is not equipped with an interval sprinkler avoid turning the
switch too far to the right. In this case you can only select positions 0 and 1.
2
3
4
2 sec.
4 sec.
8 sec.
14 sec.
20 sec.
5
6
7
Not
Off
On
Off
On
