12 Wiring diagram
BNNbOO
ID: 1138310 Issue date January 01, 2010
166
Wiring diagram key
Element Description
A1 Fuel display
B3 Horn
B4 Buzzer, ROPS2D
B19 Reversing buzzer (*)
B30 Flow divider buzzer (*)
B55 Seat switch seat contact delay buzzer (*)
C80 Capacitor for seat switch
E6 Front left indicator (*)
E7 Rear left indicator (*)
E8 Front right indicator (*)
E9 Rear right indicator (*)
E11 Front left parking light (*)
E12 Rear left parking light (*)
E13 Front right parking light (*)
E14 Rear right parking light (*)
E15 Front left low beam light (*)
E16 Front right low beam light (*)
E21 Revolving warning light (*)
E24 Rear left work light (*)
E25 Rear right work light (*)
E26 Work headlight, left on ROPS (*)
E27 Work headlight, right on ROPS (*)
E30 Front left position light (*)
E31 Front right position light (*)
E32 License plate light, rear (*)
E40 Heating, seat heating
F1 Parking light fuse
F2 Low beam light fuse
F3 Fuse, emergency stop, holding solenoid
F4 Fuse, sprinkler, horn, reverse alarm, flow divider
F5 Fuse, displays, indicators
F6 Fuse, hazard flasher
