7 Options
BNNbOO
ID: 1138310 Issue date January 01, 2010
76
Roof
The roof option serves as all-weather protection. You can use the roof to
protect from sun and rain.
Transport with ROPS folded down
During transport with the ROPS folded down, e.g. in a container or closed
truck, you must remove the whole roof.
Fitting / removing the roof
Please note the work/assembly instructions contained in the delivery: (ANW-
4397 roof option AVM-2).
Fitting the roof
Screw the roof (1) to the ROPS with
the four Allen screws (2) and washers
(3).
NOTE
Make sure that the screws are
always firmly tightened.
Roof with revolving warning light
If your roller is fitted with a revolving
warning light (1), disconnect the wing
nut of the revolving warning light (2)
before removing the roof.
Lift the warning light out of the holder.
3
1
2
1
2
