AMX Duet Module Interface Specifications
72
Tango Audio Controllers
Tango Controllers - Command Control (Cont.)
Command Description
?FWVERSION Get the device's firmware version.
This query should be issued on port 1.
Replies with FWVERSION-<version>
Example:
?FWVERSION
?INPUT Get the currently selected input source.
This query should be issued on the port matching the room number
you want to query.
Replies with INPUT-<source>,<number>
Example:
?INPUT
INPUT-<source>,<number> Set the current input source.
This command should be issued on the port matching the room/
zone you want to affect.
The <source> parameter is not used by the module due to the
device protocol and you may use it only as a place holder.
The module will select the input according to the <number> param-
eter.
<source> : INTERNAL TUNER,EXTERNAL TUNER, CD,
DVD, SATELLITE, DELPHI XM, AUDIO SERVER, OTHER
<number> : 1...8 = valid input source number
0 = disconnect
Example:
INPUT-INTERNAL TUNER,1 (connect to input 1)
INPUT-INTERNAL TUNER,0 (disconnect)
PASSBACK-<state> Enable or disable response reporting from the device. When
enabled device responses will be sent as strings to the virtual
device.
This command should be issued on port 1.
Note: By default, this is set to off at startup.
<state> : 0 = Off (default)
1 = On
Example:
PASSBACK-0
PASSTHRU-<string> Allows user the capability of sending commands directly to what-
ever unit is attached with minimal processing by the Duet module.
User must be aware of the protocol implemented by the unit to use
this command. This gives the user access to features that may not
be directly supported by the module.
For more information, see the "Adding Functions to Modules" sec-
tion below.
This command should be issued on port 1.
<string> : string to send to unit
Example:
PASSTHRU-MSSC1,0
