Programming
Overview
The chapter defines all programming commands available for the SDX Digital Switchers.
SEND_COMMANDS
The commands listed in the following sections are for the switcher only. For generic NetLinx commands, see the NetLinx
Integrated Switchers WebConsole and Programming Guide.
The commands derive their input/output port addressing from the target D:P:S.
INPUT ports range from 1-10 for Audio/Video. HDMI inputs are capable of carrying both digital audio and
video signals.
Input and Output functional distinctions are disambiguated from the overlapped port numbers by combining
them with the command name.
Port Functionality Mapping
The following table lists the port functionality mapping for the audio/video ports on the Solecis Digital Switchers:
Port Functionality Mapping
Port SDX-410-DX SDX-510M-DX SDX-810-DX Address
HDMI IN 1 1 1 1 <DevID>:1:0
HDMI IN 2 2 2 2 <DevID>:2:0
HDMI IN 3 3 n/a 3 <DevID>:3:0
HDMI IN 4 4 4 4 <DevID>:4:0
HDMI IN 5 n/a n/a 5 <DevID>:5:0
HDMI IN 6 n/a n/a 6 <DevID>:6:0
HDMI IN 7 n/a n/a 7 <DevID>:7:0
HDMI IN 8 n/a n/a 8 <DevID>:8:0
HDMI OUT 1 1 1 <DevID>:1:0
DXLINK OUT 1 1 1 <DevID>:1:0
VGA IN 3 n/a 3 n/a <DevID>:3:0
VGA IN 5 n/a 5 n/a <DevID>:5:0
USB Device n/a 12 n/a <DevID>:12:0
USB Host n/a 13 n/a <DevID>:13:0
External Buttons 14 14 14 <DevID>:14:0
AxLink Keypad 1 15 15 15 <DevID>:15:0
AxLink Keypad 2 17 17 17 <DevID>:17:0
