Instruction Manual - Solecis Digital Switchers
Appendix B - Supported Resolutions
Available Pixel Display and Refresh Rates
The available pixel display and refresh rates for the input devices connected to the switcher are listed in this appendix.
DVI, HDMI, and VGA Supported Input Resolutions
DVI, HDMI, and VGA Supported Input Resolutions
Resolution
Name
Horizontal
Active
Pixels
Vertical
Active
Lines
Refresh
(Hz)
HDMI &
DVI
Support
VGA
Support
Comments Video
Standard
640x400@85 640 400 85   VESA DMT
640x480@60 640 480 60   VESA DMT
640x480@72 640 480 72   VESA DMT
640x480@75 640 480 75   VESA DMT
640x480@85 640 480 85   VESA DMT
720x400@85 720 400 85   VESA DMT
720x480p@60 720 480 60   480p CEA 861
720x480p@120 720 480 120   480p CEA 861
720x480p@240 720 480 240   480p CEA 861
720x576p@50 720 576 50   576p CEA 861
720x576p@100 720 576 100   576p CEA 861
720x576p@200 720 576 200   576p CEA 861
800x600@56 800 600 56   VESA DMT
800x600@60 800 600 60   VESA DMT
800x600@72 800 600 72   VESA DMT
800x600@75 800 600 75   VESA DMT
800x600@85 800 600 85   VESA DMT
848x480@60 848 480 60   VESA DMT
848x480@75 848 480 75   VESA CVT
848x480@85 848 480 85   VESA CVT
1024x640@60 1024 640 60   VESA CVT
1024x768@60 1024 768 60   VESA DMT
1024x768@70 1024 768 70   VESA DMT
1024x768@75 1024 768 75   VESA DMT
1024x768@85 1024 768 85   VESA DMT
1152x864@75 1152 864 75   VESA DMT
1280x720@60 1280 720 60   VESA CVT
1280x720p@60 1280 720 60   720p CEA 861
1280x720p@100 1280 720 100   720p CEA 861
1280x720p@120 1280 720 120   720p CEA 861
1280x768@60 1280 768 60   VESA DMT
1280x768@75 1280 768 75   VESA DMT
1280x768@85 1280 768 85   VESA DMT
1280x800@60 1280 800 60   VESA CVT
1280x960@60 1280 960 60   VESA DMT
