Appendix A: Supported Input and Output Modes
157
TPI-PRO-DVI - Instruction Manual
Additional output modes for TPI-PRO-DVI are:
NOTE: Extended CEA refresh rates are recommended for DVI outputs, and may not work reliably with VGA outputs.
Additional output modes can be sent, and if a standard does not match, then VESA CVT timings will be calculated for the
output timings. The CVT timings will be standard blanking if the pixel clock is within allowable limits, or will be CVT reduced
blanking (rb) timings.
The TPI-PRO-DVI does not provide Component (YPbPr) or Interlaced outputs.
See the ORES command on page 109.
NOTE: If you are downgrading the firmware on the TPI to version 2.5.10 or earlier and you are using the 1280x800@60Hz resolution,
change the panel page resolution to a different setting since this resolution does not exist in earlier firmware versions. Failure to do so
results in your panel resolution being reset.
Standard output modes for TPI-PRO-DVI
Resolution Standard Command
720x480@60 CEA861 ‘ORES-720x480@60 CEA’
720x576@50 CEA861 ‘ORES-720x576@50 CEA’
1280x720@50 CEA861 ‘ORES-1280x720@50 CEA’
1280x720@60 CEA861 ‘ORES-1280x720@60 CEA’
1920x1080@50 CEA861 ‘ORES-1920x1080@50 CEA’
1920x1080@60 CEA861 ‘ORES-1920x1080@60 CEA’
