UDM-0808-SIG Wiring and Connections
8
UDM-0808-SIG, UDM-RX02N and UDM-ABB-8-SIG Operation /Reference Guide
Connecting a Component Video Input
1.
Connect the UDM-HD15RCA3 Breakout Cable (FG-HD15RCA3, not included) to the video source
device’s Component video output connectors (Red, Green and Blue).
2. Attach the other end of the cable to the appropriate VIDEO IN connector (A-H) on the UDM.
3. Connect the source audio to the analog (RCA) audio jacks, or digital (SPDIF) Input connector.
Connecting an S-Video Input
1.
Connect the UDM-SVID01 HD15 to SVideo Cable (FG-UDM-SVID01, not included) to the video
source’s S-Video connection.
2. Attach the other end of the cable to the appropriate VIDEO IN connector (A-H) on the UDM.
3. Connect source audio to the analog (RCA) audio jacks, or digital (SPDIF) Input connector.
Video Adapter Cables
The following adapter cables are available from AMX, to allow connecting various video input types to the
UDM-0102:
Audio & Video Formats/Resolutions/Distance
The following table provides recommended maximum distances for cable runs, based on video class type at
various resolutions:
It is important to note that the maximum distances indicated above are not absolute, but are recommended
distances that have been tested to deliver video at the specified resolutions, without significant signal
degradation. In particular, lower resolutions (640 x 480, 720 x 480 and 800 x 600) can often be delivered
significantly further than what is indicated in the table.
Several factors affect the overall quality of the displayed video, including the quality of the twisted pair cable
and connectors used, the nature of the video image itself, as well as the particulars of the installation and how
the video is displayed and viewed.
Video Adapter Cables
Name FG # Description
UDM-HD15RCA3 FG-HD15RCA3 HD-15 to 3x RCA Breakout Cable
UDM-SVID01 FG-UDM-SVID01 HD-15 to S-Video Cable Breakout Cable
Audio & Video Formats/Resolutions/Distance
Class Format Name UDM-RX02N
Composite/S-Video 720 x 480 NTSC 300 m / 1000’
720 x 576 PAL 300 m / 1000’
Component 720 x 480 480p 300 m / 1000’
720 x 576 576p 300 m / 1000’
1280 x 720 720p 300 m / 1000’
1920 x 1080 1080i 300 m / 1000’
1920 x 1080 1080p 300 m / 1000’
RGBHV 640 x 480 VGA 300 m / 1000’ *
800 x 600 SVGA 300 m / 1000’ *
1024 x 768 XGA 300 m / 1000’ *
1280 x 1024 SXGA 300 m / 1000’ *
1600 x 1200 UXGA 140 m / 460’
1920 x 1080 HD 140 m / 460’
* When using VGA modes with audio enabled, the
maximum cable distance is approximately 200 m / 650’ (UDM-RX02N).
