UDM-RX02N NetLinx Programming
50
UDM-0808-SIG, UDM-RX02N and UDM-ABB-8-SIG Operation /Reference Guide
CHANNELs
LEVELs
Levels are sent to Port 1 on the UDM-RX02N:
SEND_COMMANDs
Device SEND_COMMANDS are sent to Port 1 on the UDM-RX02N.
All text is based on a Unicode index.
Channel Function
255 This channel on shows that the Rx has a valid CAT5 connection to the UDM hub.
If channel is off the Rx is not connected correctly.
Level Function
10 Brightness - controls the gain applied to the video signal to compensate for CAT5
cable losses - a value of 0 provides no additional gain, whereas a value of 90 would
compensate for around 300m cable
13 Sharpness - controls the high frequency boost applied to compensate for cable
losses - a value of 0 provides no additional boost, whereas a value of 70 will
compensate for around 300m cable
15 Red skew - controls the delay added to a video signal to compensate for different pair
lengths in the cable - a value of 0 applies no delay, whereas a value of 31 (maximum)
applies 62nS delay
16 Green skew - controls the delay added to the green video signal
17 Blue skew - controls the delay added to the blue video signal
UDM-RX02N SEND COMMANDs
"'RP'"
Sets the protocol
used by the IR
remote.
The Rx can support a number of different remotes which are mapped through to button
pushes
Syntax:
SEND_COMMAND <DEV>, "'RP<P#>'"
Variables:
•P#:
"ENDELEO", "AMX", "SKY", "TIVO", "DIRECTV", "MIOR1", "MIO", "RC02", "RC05"
Example:
SEND_COMMAND dvRX, "'RPAMX'"
Configures the Rx to use an AMX remote.
The available remotes are:
• RC02 - grey 33 button and 13 button remotes
• ENDELEO (deprecated) - grey 33 button and 13 button remotes
• RC05 - beige 43 button remote
•AMX (deprecated) - beige 43 button remote
• SKY - Sky satellite remote
• TIVO - standard Tivo remote
• DIRECTV - standard DirecTV remote
• MIOR1 - AMX R1 remote
In all the above cases, the push and release codes are endeleo codes.
• MIO - AMX R1 remote - this setting uses all 255 push/release codes.
