AMX UDM-0808-SIG User Manual

UDM-RX02N NetLinx Programming
51
UDM-0808-SIG, UDM-RX02N and UDM-ABB-8-SIG Operation /Reference Guide
"'?RP'"
Returns the
protocol used by
the IR remote.
The Rx can support a number of different remotes which are mapped through to button
pushes.
Syntax:
SEND_COMMAND <DEV>, "'?RP'"
Example:
SEND_COMMAND dvRX, "'?RP1'"
The port would respond with RP-ENDELEO.
"'SB'"
Sets the bright-
ness of the signals
delivered to a
connected display.
Syntax:
SEND_COMMAND <DEV>,"SB<B#>'"
Variables:
• B# = brightness
0-90 = brightness value
Example:
SEND_COMMAND dvRX1,"'SB46'"
Sets the brightness to 46 (about half way).
"'?SB'"
Returns the bright-
ness of the signals
delivered to a
connected display.
Syntax:
SEND_COMMAND <DEV>,"?SB'"
Example:
SEND_COMMAND dvRX1,"'?SB'"
The command would return with SB-nn, where nn is the brightness setting.
"'SD'"
Sets the
brightness,
sharpness and
skew of the
signals delivered
to a connected
display based on
distance and cable
type.
Syntax:
SEND_COMMAND <DEV>,"SD<D#CC#>'"
Variables:
• D# = distance
0-255 = cable length in meters
• C# = cable type
"CAT5"
"CAT5e"
"CAT6"
"CAT7"
Example:
SEND_COMMAND dvRX1,"'SD100CCAT5e'"
Sets the cable compensation for 100m of CAT5e cable
"'SKB'"
Sets the skew on
the blue video
channel
Syntax:
SEND_COMMAND <DEV>,"SKB<B#>'"
Variables:
• B# = skew value (delay in 2nS intervals)
0-31 = skew value
Example:
SEND_COMMAND dvRX1,"'SKB4'"
Sets the blue skew value to 4 (adds 8nS delay to blue video)
"'SKG'"
Sets the skew on
the green video
channel.
Syntax:
SEND_COMMAND <DEV>,"SKG<G#>'"
Variables:
• G# = skew value (delay in 2nS intervals)
0-31 = skew value
Example:
SEND_COMMAND dvRX1,"'SKG17'"
Sets the green skew value to 17 (adds 34nS delay to green video).
