Installation conditions
20 Edition 03.19 qTOWER
3
/ qTOWER
3
G
Switching-on conditions
Energy supply
Operating voltage
Line frequency
100 V, 115 V, 230 V
50 – 60 Hz
Power consumption
max. 850 W
Instrument fuses
Mains voltage
Instrument fuses
100 V, 115 V, 230 V
2 x 10 AT / 250 V
4.3 Space requirement
NOTICE
When opening the qTOWER³ the upper device hood tilts back. Allow adequate space for
this.
qTOWER
3
Height [cm]
Width [cm]
Depth [cm]
closed
59
27.5
27.5
open
70
27.5
50
The open device has a space requirement of 70 cm x 27.5 cm x 50 cm (H x W x D).
Allow adequate space for placement of the device. In addition, keep a safety distance of
at least 10 cm to other equipment or walls!
Additional space may be required next to the qTOWER
3
for a PC, monitor and possibly
a printer. The PC, monitor and printer may also be placed on a separate table.
