- 22 -
Programming of valve-group irrigation
4. Setting Irrigation Duration for each Valve
In this operation the controller is programmed to operate the selected program at set cyclic times.
The cycle can be set from one day up to 30 days. The cyclic time will be identical for all of the valves
attributed to the selected program.
Cycle Time Selection
• Turn selector to Irrigation Days/Cycle mode (in Programs A, B and C)
• On the display panel the symbol of the current program will appear, along with the type of program
(weekly/cyclic), duration symbol
and valve symbol in line with the valve you have designated.
• Press on
. until symbol and caption DAYS 1 (Irrigation cycle of 1 day) appear.
• Press on
. DAYS 1 blinks.
• Set cycle time using
or as necessary up to DAYS 14 (14 days).
ATTENTION!
Irrigation duration set at 0:00 will
not be opened.
The selector should be returned to the TIME/DAY mode
following modification or ending of the program.
