- 30 -
3. Garden Lighting Program
It is possible to operate garden lighting only by the weekly irrigation program.
Programming the lighting is a separate program operation. The master valve will not open.
(Operation of sensor, fertilization supplementation and suspension will not effect lighting operation).
Garden lighting operation is adaptable only to relay of 24VAC up to mA 20.
1. Programming Garden Lighting
• Turn selector to Program Selection mode.
• One of the programs will appear on display panel. Press on
button until the Light program
appears.
.
• Press on
button. The word OFF will begin to blink. Pressing the button will make the ON
button blink. Garden lighting programming has been selected.
• Press
button to close program (OFF).
• Continue programming desired data for garden lighting according to instructions of weekly
programming on page 16.
The selector should be returned to the TIME/DAY mode
following modification or ending of the program.
Advanced Programming
