Version 4.2 rev 06 Oct 2020
8.2 x 8.2 mm / 512 x 512 sensor
Lowest Noise Imaging EMCCD
Mechelle
1.5 supplied coMponents
The Andor Mechelle is supplied with the following standard components:
Description Quantity
Mechelle 5000 echelle spectrograph
1
Description Quantity
I
2
C, shutter and
temperature cable
1
SMA adapter
(and insertion tool)
1
Description Quantity
50 µm core,
UV-enhanced bre optic
cable (
ACC-ME-OPT-8004)
1 x 2m
Solis or Mechelle SDK-
Software
(if ordered)
-
NOTE: Refer to Camera Specications sheet for parts supplied with the specic camera model.
Slit type and model, and optional shutter are ordered separately.
1.5.1 optional coMponents
Optional and replacement parts are listed below:
Description Order Code
Mercury-Argon calibration lamp with SMA connector ACC-LK-HGAR-OCE
Deuterium-Halogen lamp, radiometrically calibrated (230 to 1,050 nm)
LK-DHRD-OCE-CAL
UV-NIR light collector/collimator with alignment laser for F/# = 2 collection ME-OPT-0007
Mechelle shutter unit (recommended when using iKon-M DU934P-yy-9FL)
ME-SHT-9002
Mechelle 25 x 25 μm slit ME-SLT-25x25
Mechelle 10 x 50 μm slit ME-SLT-10x50
Mechelle 50 x 25 μm slit ME-SLT-50x25
Mechelle 25 x 50 μm slit ME-SLT-25x50
Mechelle 50 x 50 μm slit ME-SLT-50x50
Mechelle 100 x 50 μm slit ME-SLT-100x50
Mechelle 200 x 50 μm slit ME-SLT-200x50
