27
Version 4.2 rev 06 Oct 2020
8.2 x 8.2 mm / 512 x 512 sensor
Lowest Noise Imaging EMCCD
Mechelle
3.3 calibRation souRce
To wavelength calibrate the Mechelle spectrograph a spectral calibration source is needed. A Mercury/Argon lamp is
recommended for Mechelle calibration. Example wavelengths shown below- please refer to information suplied with
your reference lightsource.
Hg Wavelengths (nm) Ar Wavelengths (nm)
253.652 696.543
296.728 706.722
302.150 714.704
302.347 727.294
313.155 738.398
313.184 750.387
334.148 763.511
365.015 772.376
365.484 794.818
404.656 800.616
407.783 811.531
433.922 826.452
434.749 842.465
435.833 852.144
491.607 866.794
546.074 912.297
576.960 922.450
579.066
