Mechelle
The sub-image area required is calculated by the software and displayed in the image window (#0) (see gure 21
below). Only the sub-image is then read out and a sub-spectrum is extracted from it.
NOTE: In Full Spectrum mode, the software automatically calculates the background subtracted from spectrum.
In Sub-spectrum mode, the software does not calculate the background therefore a background corrected is
required.
Figure 21: Example of a sub-image area
