Flat cable connection on the LED board and keyboard
Connecting the flat cables (8) and (9) pay attention not to bend the pins of the cables.
LCD display replacing
To remove the LCD screen, first remove the CPU board.
To remove the display you must remove the metal profile shown in the picture.
PIN
ATTENZIONE A NON PIEGARE I PIN
PROFILO FISSAGGIO
DISPLAY
ATTENTION: DON’T BEND THE PINS
DISPLAY FIXING
PROFILE
