Anritsu s331c Maintenance Manual

General Information 1-3 Recommended Test Equipment
S3xxE MM PN: 10580-00253 Rev. J 1-3
Table 1-2. Test Equipment Required for Cable and Antenna Analyzer Verification
Instrument Critical Specification Recommended Manufacturer/Model
Frequency Counter Frequency: 2 GHz Anritsu Model MF2412B
Open/Short Frequency: DC to 18 GHz Anritsu Model 22N50
Termination Frequency: DC to 18 GHz
Return Loss: 40 dB min.
Anritsu Model 28N50-2
RF Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(f), 50 ohm
Anritsu Model 15NN50-1.5C
6 dB Offset Termination Frequency: DC to 6.0 GHz Anritsu Model SC7424
20 dB Offset Termination Frequency: DC to 6.0 GHz Anritsu Model SC7423
Table 1-3. Test Equipment Required for Verifying Options
Instrument Critical Specification Recommended Manufacturer/Model
Termination Frequency: DC to 18 GHz
Return Loss: 40 dB min.
Anritsu Model 28N50-2
Termination Frequency: DC to 18 GHz
Return Loss: 40 dB min.
Anritsu Model 28NF50-2
Adapter 40 ohm Load Anritsu Model T2904
Adapter 78 ohm Load Anritsu Model T3536
Adapter 105 ohm Load Anritsu Model T3377
Adapter SMA to BNC(f) Pomona 4290 or equivalent
Adapter GPS Terminator Amphenol B1004A1-ND3G-93R-0.05-1W
or equivalent
Adapter Frequency: DC to 20 GHz
N(m) to N(m), 50 ohm
Anritsu Model 34NN50A
Adapter Frequency: DC to 20 GHz
K(m) to N(f), 50 ohm
Anritsu Model 34RKNF50
GPS Antenna Anritsu 2000-1528-R
Coaxial Cable Frequency: DC to 18 GHz
N(m) to N(m), 50 ohm
Anritsu Model 15NN50-1.5C
Coaxial Cable BNC(m) to BNC(m), 50 ohm Any (Qty 2) Anritsu Model 2000-1627-R
Synthesized Signal Source Frequency: 0.1 Hz to 20 GHz
Power Output to +13 dBm
Anritsu Model MG3692A or B with
Options 2A, 4, 22, 15
a
a. Option 15 is required for MG3692A models to achieve power of +13 dBm. MG3692B models do not require Option 15.
Power Meter Power Range: − 70 to +20 dBm Anritsu Dual Channel Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –67 to +20 dB
Anritsu Model MA2442D (quantity 2)
Fixed Attenuator 10 dB Attenuation Aeroflex/Weinschel Model 44-10
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
Frequency Reference Frequency: 10 MHz Symmetricom Model RubiSource T&M
