A-3 Test Records for Options Verification
S3xxE MM PN: 10580-00253 Rev. J A-13
A-3 Test Records for Options Verification
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-16. Option 10, Bias Tee
Voltage
Setting Measured Values
Voltage
Specification
Current
Specification
105 ohm Load, Low Current
12 V V mA 12 ± 1.2 V 85 mA to 145 mA
18 V V mA 18 ± 1.8 V 142 mA to 202 mA
24 V V mA 24 ± 2.4 V 199 mA to 259 mA
40 ohm Load, High Current
15 V V mA 15 ± 1.5 V 325 mA to 425 mA
78 ohm Load, High Current
32 V V mA 32 ± 3.2 V 370 mA to 450 mA
Table A-17. Option 21, VNA System Dynamic Range Verification
Frequency Measured Value Specification
2MHz to 4GHz dB ≤ –80 dB
> 4GHz to 6GHz (S36xE) dB ≤ –70 dB
