A-2 Test Records for Cable and Antenna Analyzer Verification
A-12 PN: 10580-00253 Rev. J S3xxE MM
A-2 Test Records for Cable and Antenna Analyzer Verification
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-14. VNA Frequency Accuracy
Frequency Measured Value Specification
2 GHz (2000 MHz) MHz ± 5.0 kHz (± 2.5 ppm)
Table A-15. VNA Return Loss Accuracy Verification
Return Loss Measured Value Specification
Start Frequency = 2 MHz, Stop Frequency = 4 GHz (S33xE) or 6 GHz (S36xE)
6dB dB –4.8 dB ≥ x ≥ –7.2 dB
20 dB dB –18.3 dB ≥ x ≥ −21.7 dB
