Anritsu s331c Maintenance Manual

A-1 Test Records for Spectrum Analyzer Verification
S3xxE MM PN: 10580-00253 Rev. J A-11
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-11. Spectrum Analyzer DANL with Pre Amp Off
Start Freq Stop Freq RBW VBW
Measured Value at
100 kHz RBW
Calculated for
10 Hz RBW Specification
10 MHz 2.4 GHz 100 kHz 1 kHz dBm dBm ≤ –131 dBm
2.4 GHz 4.0 GHz 100 kHz 1 kHz dBm dBm ≤ –127 dBm
4.0 GHz
(S362E)
5.0GHz 100kHz 1kHz dBm dBm ≤ –124 dBm
5.0 GHz
(S362E)
6.0GHz 100kHz 1kHz dBm dBm ≤ –116 dBm
Table A-12. Spectrum Analyzer DANL with Pre Amp On
Start Freq Stop Freq RBW VBW
Measured Value at
100 kHz RBW
Calculated for
10 Hz RBW Specification
10 MHz 2.4 GHz 100 kHz 1 kHz dBm dBm ≤ –147 dBm
2.4 GHz 4.0 GHz 100 kHz 1 kHz dBm dBm ≤ –144 dBm
4.0 GHz
(S362E)
5.0GHz 100kHz 1kHz dBm dBm ≤ –140 dBm
5.0 GHz
(S362E)
6.0GHz 100kHz 1kHz dBm dBm ≤ –133 dBm
Table A-13. Third Order Intercept (TOI) Verification
Frequency Measured Max Value
Calculated TOI
TOI = –20 + [(–20 – max) / 2] Specification
800 MHz dBm dBm ≥ 16 dBm
2400 MHz dBm dBm ≥ 20 dBm
