A-1 Test Records for Spectrum Analyzer Verification
A-10 PN: 10580-00253 Rev. J S3xxE MM
S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________
Serial Number: _______________ Options: ___________________________________________________
Table A-9. Spectrum Analyzer Residual Spurious with Preamp Off
Start Freq. Stop Freq. RBW VBW Measured Values Specification
10MHz 50MHz 1kHz 300Hz dBm ≤ –90 dBm
50 MHz 2.0 GHz 3 kHz 10 kHz dBm ≤ –90 dBm
2.0GHz 4.0GHz 1kHz 1kHz dBm ≤ –90 dBm
4.0 GHz
(S362E only)
5.0GHz 1kHz 3kHz dBm ≤ –90 dBm
5.0 GHz
(S362E only)
5.2GHz 1kHz 1kHz dBm ≤ –90 dBm
5.2 GHz
(S362E only)
5.7 GHz 300 Hz 3 kHz dBm ≤ –90 dBm
5.7 GHz
(S362E only)
5.9 GHz 300 Hz 3 kHz dBm ≤ –90 dBm
5.9 GHz
(S362E only)
6.0GHz 1kHz 100Hz dBm ≤ –90 dBm
Table A-10. Spectrum Analyzer Residual Spurious with Preamp On
Start Freq. Stop Freq. Measured Values Specification
10 MHz 1.0 GHz dBm ≤ –90 dBm
1.0GHz 4.0GHz dBm ≤ –90 dBm
4.0 GHz (S362E only) 6.0 GHz dBm ≤ –90dBm
To Next Page
