General Information 1-4 Replaceable Parts
S3xxE MM PN: 10580-00253 Rev. J 1-5
3-67304-9 Model S331E ID Label
3-67304-6 Model S332E ID Label
3-67304-5 Model S361E ID Label
3-67304-7 Model S362E ID Label
ND70320 GPS Module (Opt 31)
ND72101 Ethernet PCB Assy (Opt 411)
ND82421 CPRI PCB Assy (Opt 751)
3-15-147 LCD Display, used with Inverter PCB (all unit s/n < 1329107, and some units with s/n
< 1334000)
3-15-165 LCD Display for S331E unit serial number range: 1334000 < s/n < 1608000, All other
S3xxE unit serial number range 1334000 < s/n < 1606000
3-15-174 LCD Display for S331E unit s/n > 1608000, all other S3xxE unit s/n > 1606000
3-68567-3 Inverter PCB (only used on all units with s/n < 1329107 and some units with s/n <
1334000)
2000-1654-R Soft Carrying Case
ND73191 Front Case with Gasket (Excludes LCD, touch screen, encoder and keypad assemblies.)
ND74508 Front Case Kit (Includes Keypad PCB, Rubber Keypad, Encoder, Encoder knob and
Speaker assy
ND73199 Back Case (Excludes Tilt Bail)
ND73201 Battery Door
633-75 7500 mAH Li-ion Battery Pack
3-513-100 RF In Connector and RF Out Connector
40-187-R AC to DC Power Converter
3-410-103 Encoder (excluding knob)
3-61360-2 Knob (excluding encoder)
ND73200 Tilt Bail Assembly
3-69770-2 Top Bumper (Gray)
3-69771-2 Bottom Bumper (Gray)
ND81940 Fan Assembly
ND75294 Main Numeric Keypad PCB (Non-Locking connector)
ND75295 Main Numeric Keypad PCB (Locking connector)
3-72773 Rubber Keypad
3-72767 Keypad Washer
3-905-2744 Keypad Screw
ND73192 Speaker
3-72758 Vent 1 (Fan Vent, above battery door)
3-72759 Vent 2 (Intake Vent, top vent on keypad side)
3-72760 Vent 3 (Battery Vent, bottom vent on keypad side)
3-72771 Cable, Keypad to Main PCB, 15 cm, white (Non-locking connectors)
3-74842-3 Cable, Keypad to Main PCB, 15 cm, white (Locking connectors)
3-72770 Cable, Keypad to Inverter PCB, 6cm, white
Table 1-4. List of Replaceable Parts
Part Number Description
