A-1 Test Records for Spectrum Analyzer Verification

A-4 PN: 10580-00253 Rev. J S3xxE MM

S3____E Firmware Rev: ______________ Operator: _________________ Date: _____________

Serial Number: _______________ Options: ___________________________________________________

Table A-6. Spectrum Analyzer 50 MHz Absolute Amplitude Accuracy

Input Power Level Reference Level Input Atten. Level Measured Reading Specification

0 dBm 10 dBm 30 dB dBm ± 1.25 dB

–4 dBm 10 dBm 30 dB dBm ± 1.25 dB

–10 dBm 0 dBm 20 dB dBm ± 1.25 dB

–14 dBm 0 dBm 20 dB dBm ± 1.25 dB

–20 dBm –10 dBm 10 dB dBm ± 1.25 dB

–24 dBm –10 dBm 10 dB dBm ± 1.25 dB

–30 dBm –20 dBm 0 dB dBm ± 1.25 dB

–34 dBm –20 dBm 0 dB dBm ± 1.25 dB

–40 dBm –30 dBm 0 dB dBm ± 1.25 dB

–44 dBm –30 dBm 0 dB dBm ± 1.25 dB

–50 dBm –40 dBm 0 dB dBm ± 1.25 dB

Turn Pre-Amp On (for the below measurement)

–44 dBm –40 dBm 10 dB dBm ± 1.25 dB

–50 dBm –45 dBm 5 dB dBm ± 1.25 dB

Table A-7. Spectrum Analyzer Absolute Amplitude Accuracy Across Frequency Setup Table

Frequency

Required Sensor B

reading for –2 dBm @

Attenuator output

Required Sensor B

reading for –30 dBm @

Attenuator output

Required Sensor B

reading for –50 dBm @

Attenuator output

10.1 MHz dBm dBm dBm

50 MHz dBm dBm dBm

100 MHz dBm dBm dBm

500 MHz dBm dBm dBm

1000 MHz dBm dBm dBm

2000 MHz dBm dBm dBm

3000 MHz dBm dBm dBm

3990 MHz dBm dBm dBm
