1-10 Cell Master Specifications General Information
1-6 PN: 10580-00250 Rev. K Cell Master UG
Trace Storage
Time and date stamping of measurement data is automatic. The internal memory provides
for the storage and recall of up to 1000 measurement setups and up to 1000 traces using
Master Software Tools (MST). External storage can be used for bulk measurement storage.
Measurements and setups can be stored in a USB flash drive or transferred to a PC by using
the included USB cable.
1-10 Cell Master Specifications
Refer to the Cell Master Technical Data Sheet (P/N 11410-00485) for general specifications,
detailed measurement specifications for all available measurement modes, ordering
information, power sensors, and available accessories. The data sheet is included with the
instrument and also available on the Anritsu website: http://us.anritsu.com.
1-11 Preventive Maintenance
Cell Master preventive maintenance consists of cleaning the unit and inspecting and cleaning
the RF connectors on the instrument and all accessories. Clean the Cell Master with a soft,
lint-free cloth dampened with water or water and a mild cleaning solution.
Clean the RF connectors and center pins with a cotton swab dampened with denatured
alcohol. Visually inspect the connectors. The fingers of the N(f) connectors and the pins of the
N(m) connectors should be unbroken and uniform in appearance. If you are unsure whether
the connectors are undamaged, gauge the connectors to confirm that the dimensions are
correct.
Visually inspect the test port cable(s). The test port cable should be uniform in appearance,
and not stretched, kinked, dented, or broken.
1-12 Calibration Requirements
Anritsu recommends annual calibration and performance verification by local Anritsu
service centers. The Cable and Antenna Analyzer mode requires calibration standards for
OPEN, SHORT, and LOAD (OSL) or InstaCal module, which are sold separately.
Note
Not all after-market USB drives are compatible with the Cell Master. Many drives
come with a second partition that contains proprietary firmware. This partition must
be removed. Only one partition is allowed. Refer to the individual manufacturer for
instructions on how to remove it. You might also try reformatting a drive that
contains a single partition using FAT32 format.
Caution To avoid damaging the display or case, do not use solvents or abrasive cleaners.
Note
Anritsu recommends allowing the instrument to warm up to typical operation
temperature (~15 minutes) before calibrating.
