5-3 System Menu System Operations
5-6 PN: 10580-00251 Rev. T MS2712E/13E User Guide
Power-On Menu
Key Sequence: Shift, System (8) > System Options > More > Power–On
Figure 5-5. Remote Access Password Dialog
Power Switch: Press this submenu key to set the instrument for normal use
of the On/Off button on the instrument front panel.
When DC Applied: Press this submenu key to set the instrument to
automatically restart when DC power is applied to the External Power
connector (see Figure 2-14 on page 2-15). Refer to “External Power On”
on page 3-8.
Back: Press this submenu key to return to the “System Options 2/2 Menu”
on page 5-5.
Figure 5-6. Power–On Menu
Back
Power–On
Power Switch
When DC
Applied
To Next Page
