Web Remote Control 9-3 Web Remote Control Interface
MS2712E/13E User Guide PN: 10580-00251 Rev. T 9-7
Capture Screen
Captures a JPEG image of the current instrument display and saves it directly to internal
memory. A file name is automatically created using the current date and time stamp. The
captured display is loaded to the browser page, under the menu bar. See Figure 9-4. In
Windows, you can right-click on the screen image and select Copy. With iOS, press and hold
on the picture. This makes it easy to create documentation using screen captures.
Capture Trace
Opens an input dialog to enter a name for the trace to be saved. See Figure 9-5. After clicking
Save, a confirmation dialog opens to indicate the trace was successfully saved to the
instrument.
Depending on the browser and operating system used, different prompts may appear. Some
operating systems like iOS may not support file saving from a browser.
Figure 9-4. Capture Screen Page
Figure 9-5. Capture Trace Page
