General Information 1-2 Instrument Description
MS2712E/13E User Guide PN: 10580-00251 Rev. T 1-3
Read the Handheld Instruments Product Information, Compliance, and Safety Guide
(PN: 10100-00065) for important safety, legal, and regulatory notices before operating the
equipment. For additional information and literature covering your product, visit the product
page of your instrument and select the Library tab:
• http://www.anritsu.com/en-US/test-measurement/products/ms2712e
• http://www.anritsu.com/en-US/test-measurement/products/ms2713e
Contacting Anritsu for Sales and Service
To contact Anritsu, visit the following URL and select the services in your region:
http://www.anritsu.com/contact-us
1-2 Instrument Description
The Spectrum Master MS2712E and MS2713E are integrated multi-functional test
instruments that eliminate the need to carry and learn multiple test sets. The Spectrum
Master can be configured to include: spectrum analyzer, interference analyzer with
interference mapping capabilities, coverage mapping, channel scanner, gated sweep,
tracking generator, power meter, high accuracy power meter, and AM/FM/PM analyzer.
In addition, the Spectrum Master can be configured to include 3GPP, 3GPP2, IEEE 802.16,
ISDB-T, and PIM analyzer. A GPS receiver can be added to both the MS2712E and MS2713E
Spectrum Master models.
The bright 8.4 in TFT color display provides easy viewing in a variety of lighting conditions.
All Spectrum Master models are equipped with a Li-Ion battery delivering more than three
hours of battery life.
The combination of a touch screen and keypad enables users to navigate menus with the
touch screen and enter numbers with the keypad.
The internal memory is large enough to store approximately 2,000 traces or setups.
Measurements and setups can also be stored in a USB flash drive or transferred to a PC using
the included USB cable.
Note
Not all after-market USB drives are compatible with the MS2712E/13E. Many
drives come with a second partition that contains proprietary firmware. This
partition must be removed. Only one partition is allowed. Refer to the individual
manufacturer for instructions on how to remove it. You may also try reformatting a
drive that contains a single partition using FAT32 format.
